HIKMICRO LYNX 2.0 LH35 35mm 384x288 12mic <20mK Thermal Monocular

Hunting & Shooting > Night Vis & Thermal > Bino/Monocular

LYNX 2.0 LH35 35mm 384x288 Mono

HIKMICRO LYNX 2.0 LH35 35mm 384x288 12mic <20mK Thermal Monocular

$2,699.00

Product Details

Description

Lightweight & Compact Compact and light with a very comfortable and robust feel to it, the LYNX Monocular has the ultimate thermal performance housed in a small package. With advanced engineering, the refresh rate is smooth and fast – eliminating the need for recalibration as you scan your hunting zone.

Specifications

Featuring the 3.3x base magnification and a field of view 13 meters @100 meters, the LH35 2.0 is equipped with 384 sensors, a 12-micrometer pixel pitch, and 20 mK high thermal sensitivity detectors.

It is designed to elevate the excitement of every hunter, whether in the forest or field, with a remarkable detection range, reaching up to 1800 meters.

Key Features

High sensitivity

Thermal Module NETD < 20 mK (@25°C, F# = 1.0)

384 × 288 Resolution with 12 μm detector
1024 × 768 Resolution 0.39-inch OLED display
Replaceable and rechargeable Li-ion battery
338 g lightweight, with a compact and ergonomic design
Up to 6.5 hours of continuous operation Specification

Thermal Module

Image Sensor: VOx Uncooled Focal Plane Arrays
Max. Resolution: 384 × 288
Frame Rate: 50 Hz
Pixel Interval: 12 μm
Response Waveband: 8 μm to 14 μm
NETD: Less than 20 mK (@25°C), F# = 1.0
Lens (Focal Length): 35 mm, f1.0
Focus Mode: Manual Focus
Detection Range: 1800 m
Min. Focusing Distance: 3.5 m
Magnification: 3.3 × to 26.4 × (8 ×)
Field of View(H × V), Degrees/ m @100 m: 7.5° × 5.7°/13.1 m × 10.0 m

Image Display

Display: 1024 × 768, 0.39 inch, OLED
Palettes: Black Hot, White Hot, Red Hot, Fusion
FFC (Flat Field Correction) Mode: Auto, Manual, External Correction
Exit Pupil: 6 mm
Eye Relief: 20 mm
Diopter (Range): -5 D to +3 D
Brightness Adjustment: Yes
Tone Adjustment: Cold, Warm
Contrast Adjustment: Yes

System

Record Video: Yes
Capture Snapshot: Yes
Audio Recording: Yes
Standby Mode: Yes
Storage: Built-in EMMC (16 GB)
PIP: Yes
Hotspot: Yes
Hot Track: Yes
Distance Measurement: Yes

Power Supply

Battery Type: Replaceable and Rechargeable Li-ion Battery
Battery Operating: Time 6.5-hour continuous running with CVBS and hotspot function off (@25°C)
Type-C

Power Supply: 5 VDC, 2 A

Supports External

General

Protection Level: IP67
Dimension: 193.0 mm × 56.0 mm × 62.0 mm
Weight: 338 g without battery
Working Temperature: -30°C to +55°C

Product Code:LH35 2.0

Barcode:6974004646813

Brand:Huntsman Optics

Type:Bino/Monocular
