ITM Lifting Shoulder Eyebolt Din 580 - 10mm. 0.23T Features

• Galvanised finish

• Specifications, batch and brand markings as per Australian Standards requirements

• Tested and certified to AS 2317 Specifications

• Thread: M10

• W.L.L (t): 0.23

• Dimension D (mm): 10

• Dimension D1 (mm): 25

• Dimension D2 (mm): 25

• Dimension D3 (mm): 10

• Dimension H (mm): 45

• Dimension H1 (mm): 17

• Dimension W (mm): 45
