ITM Lifting Shoulder Eyebolt Din 580 - 22mm - 1.5T Features

• Galvanised finish

• Specifications, batch and brand markings as per Australian Standards requirements

• Tested and certified to AS 2317 Specifications

• Thread: M20

• W.L.L (t): 1.2

• Dimension D (mm): 20

• Dimension D1 (mm): 40

• Dimension D2 (mm): 40

• Dimension D3 (mm): 16

• Dimension H (mm):71

• Dimension H1 (mm): 30

• Dimension W (mm): 72
