HIKMICRO LYNX 2.0 LH15 15mm 384x288 12mic <20mK Thermal Monocular

Hunting & Shooting > Night Vis & Thermal > Bino/Monocular

LYNX 2.0 LH15 15mm 384x288 Mono

HIKMICRO LYNX 2.0 LH15 15mm 384x288 12mic <20mK Thermal Monocular

$1,899.00

Product Details

Description

Lightweight & Compact Compact and light with a very comfortable and robust feel to it, the LYNX Monocular has the ultimate thermal performance housed in a small package. With advanced engineering, the refresh rate is smooth and fast – eliminating the need for recalibration as you scan your hunting zone.

Specifications

Featuring an impressive field of view spanning 43 meters, equipped with 384 sensors and boasting a 12 micrometer pixel pitch of high thermal sensitivity of NETD < 20mK, the LH15 2.0 is designed to elevate the excitement of every forest hunter with a manual focus feature.

Not only that, but field hunters will also appreciate its remarkable detection range, reaching up to 750 meters.

Key Features

High sensitivity

Thermal Module NETD < 20 mK (@25°C, F# = 1.0)

384 × 288 Resolution with 12μm detector
1024 × 768 Resolution 0.39-inch OLED display
Replaceable and rechargeable Li-ion battery
270 g lightweight, with a compact and ergonomic design
Up to 6.5 hours of continuous operation Specification

Thermal Module

Image Sensor: VOx Uncooled Focal Plane Arrays
Max. Resolution: 384 × 288
Frame Rate: 50 Hz
Pixel Interval: 12 μm
Response Waveband: 8 μm to 14 μm
NETD: Less than 20 mK (@25°C), F# = 1.0
Lens (Focal Length): 15 mm, f1.0
Detection Range: 750 m
Min. Focusing Distance: 1.5 m
Magnification: 1.4x to 11.2x (8x)
Field of View(H × V), Degrees/ m @100m: 17.5° × 13.1°/30.8 m × 23.0 m

Image Display

Display: 1024 × 768, 0.39 inch, OLED
Palettes: Black Hot, White Hot, Red Hot, Fusion
FFC (Flat Field Correction) Mode: Auto, Manual, External Correction
Exit Pupil: 6 mm
Eye Relief: 20 mm
Diopter (Range): -5 D to +3 D
Brightness Adjustment: Yes
Tone Adjustment: Cold, Warm
Contrast Adjustment: Yes

System

Record Video: Yes
Capture Snapshot: Yes
Audio Recording: Yes
Standby Mode: Yes
Storage: Built-in EMMC (16 GB)
PIP: Yes
Hotspot: Yes
Hot Track: Yes
Distance Measurement: Yes

Power Supply

Battery Type: Replaceable and Rechargeable Li-ion Battery
Battery Operating Time: 6.5-hour continuous running with CVBS and hotspot function off (@25°C)
Type-C

Power Supply: 5VDC, 2 A

Supports External

General

Protection Level: IP67
Dimension: 164.0 mm × 56.0 mm× 60.8 mm
Weight: 272 g without battery
Working Temperature: -30°C to +55°C

Product Code:LH15 2.0

Barcode:6974004644079

Brand:Huntsman Optics

Type:Bino/Monocular

Availability:In Stock
