RAPTOR RQ50L 50mm 640x512 LRF Bino

HIKMICRO RAPTOR RQ50L 50mm 640x512 12mic <20mk NV 850nm Binoculars with LRF

$8,999.00

Product Details

Specifications

HIKMICRO RAPTOR series is a powerful and innovative handheld thermal and digital night vision binocular which adopts a 12 μm infrared thermal sensor with NETD < 20 mK sensitivity, 2560 × 1440 low illumination optical sensor with built-in adjustable IR Illuminator, and a precise built-in.

Key Features

640 × 512 Resolution with 12 μm Thermal sensor
High sensitivity thermal detector NETD < 20 mK (@25°C, F# = 1.0)
Super large Aperture f/0.9 thermal lens
2560 × 1440 high Resolution CMOS sensor
Built-in 850 nm IR Illuminator *

Laser rangefinder,1000 m measuring distance(with an accuracy of ± 1 m)

Thermal detection range up to 2600 m
Support thermal mode, optical mode, and image fusion mode
1024 × 768 Resolution 0.39-inch OLED display
Support PIP, GPS, DMC, Local Album, hotspot etc. intelligent features
Support video & Snapshot recording, built-in EMMC (64 GB) Specification

Laser Rangefinder

Max. Measuring Range: 1000 m
Safety Class for Laser: Class 1
Wavelength: 905 nm
Measurement Accuracy: ± 1 m

Thermal Module

Image Sensor: VOx Uncooled Focal Plane Arrays
Max. Resolution: 640 × 512
Pixel Interval: 12 μm
NETD: < 20 mk (@25°C, F# = 1.0)
Lens (Focal Length): 50 mm
Aperture: F0.9
Digital Zoom: 1 ×, 2 ×, 4 ×, 8 ×, 16 ×
Magnification: 3.4x - 54.4x (16x)
Detection Range: 2600 m
Min. Focusing Distance: 5 m
Focus Mode: manual
Frame Rate: 25 Hz
Field Of View (H×V), Degrees/m @100m: 8.8° × 7.0° (H × V)/ 15.4 m × 12.2 m Optical Module
Image Sensor: 1.88” Progressive Scan CMOS
Max. Resolution: 2560 × 1440
Focal Length: 31 mm
Aperture: F1.2
Image Enhancement: Yes
Min. Illumination: 0.001 lux @ (F1.0, AGC On)
Smart IR: Yes IR Illuminator
Wavelength: 850 nm
Viewing Range At Night: 400 m

Image Display

Display: 0.39 inch, OLED, 1024 × 768
Diopter (Range): -5 D to +3 D
Optical Mode: Day, Night, Auto, Defog
FFC (Flat Field Correction) Mode: Auto, Manual, External Correction
Image Mode: Optical, Fusion, White Hot, Black Hot, Red Hot, Image Fusion
Image Pro: Yes

System

Built-In Memory: 64 GB
Multiple Language: Yes
Audio Recording: Yes
Record Video: MP4, 1600 × 1200
Capture Snapshot: JPEG, 1600 × 1200
Local Album: Yes
Standby Mode: Yes
Proximity Sensor: Yes
Hotspot: Yes
Hot Track: Yes
GPS: Yes
Digital Magnetic Compass: Yes
Supported Application: HIKMICRO Sight
PIP: Yes

Power Supply

Battery Type: Replaceable and rechargeable Li-ion battery
Battery Operating Time: 8 hours continuous running with hotspot function off (@25°C)
TYPE-C

General

Protection Level: IP67
Working Temperature: -30°C to 55°C
Working Humidity: < 90%
Storage Temperature: -40°C to 70°C
Interpupillary Adjustment Range: 60 mm to 70 mm
Eye-Relief: 15 mm
Dimension: 217.5 mm × 155.0 mm × 87.5 mm
Weight: 1120 g
Accessory: Battery Charger, Power Cable, Lens Cloth, Two Wrist Straps, Neck Strap, Quick Start Guide, Six Batteries, Adaptor, Carrying Case
Mounting Adapter: 1/4“-20-UNC

Product Code:RQ50L

Barcode:6974004642143

Brand:Huntsman Optics

Type:Bino/Monocular

Availability:In Stock
