HIKMICRO HABROK 4K HQ35L 35mm 640x512 12mic <20mK NV 850nm Binoculars with LRF

Hunting & Shooting > Night Vis & Thermal > Bino/Monocular

HABROK 4K HQ35L 35mm 640x512 LRF Bino

HIKMICRO HABROK 4K HQ35L 35mm 640x512 12mic <20mK NV 850nm Binoculars with LRF

$6,799.00

Product Details

Description

Enhanced Resolution The Habrok Pro & 4K models combine thermal and digital optical channels, enhancing outdoor experiences. Compact like traditional binoculars but packed with advanced tech. Detect in thermal, view in optical, and record to built-in memory.

Specifications

HIKMICRO HABROK HQ35L4K 5.5-22x60 multi-spectrum binocular is equipped with an 20 mK NETD, 640 × 512 thermal detector @35 mm thermal lens and an advanced 4K digital detector with 60 mm lens, ensuring perfect image quality and detail recognition in various weather and light conditions.

Combined with a 1000 m.

Key Features

640 × 512 Resolution @12 μm thermal detector
High sensitivity

Thermal Module NETD < 20 mK (@25°C, F# = 1.0)

35 mm, F1.0 lens with thermal detection range up to 1800 m
3840 × 2160 4K ultra high-Resolution CMOS detector
1920 × 1080 Resolution 0.49-inch OLED display
Two 850 nm & 940 nm replaceable IR Illuminators and

Laser Rangefinder of 1000 m distance

8 h+ continuous operation time with replaceable battery
798 g lightweight, with a compact and ergonomic design Specification

Laser Rangefinder

Safety Class for Laser: Class 1
Wavelength: 905 nm
Max. Measuring Range: 1000 m
Measurement Accuracy: ±1 m
Min. Measuring Range: 10 m

Thermal Module

Image Sensor: VOx Uncooled Focal Plane Arrays
Max. Resolution: 640 × 512
Frame Rate: 50 Hz
Pixel Interval: 12 μm
Response Waveband: 8 μm to 14 μm
NETD: Less than 20 mK (@25°C), F#=1.0
Lens (Focal Length): 35 mm, F1.0
Focus Mode: Focus Ring
Detection Range: 1800 m
Min. Focusing Distance: 3.5 m
Magnification: 3.0 × to 22.0 × (7.3 ×)
Field of View(H × V), Degrees/ m @100 m: 12.5° × 10.1° / 22.0 m × 17.6 m Optical Module
Image Sensor: 1/1.8'' Progressive Scan CMOS
Max. Resolution: 3840 × 2160
Focal Length: 60 mm, F2.2
Min. Working Distance: 3 m
Focus Mode: Focus Ring
Magnification: 5.5 × to 22.0 × (4 ×)
Field of View (H × V), Degrees/ m @100 m: 7.3° × 4.1° / 12.6 m × 7.2 m
Smart IR: Yes
IR Illuminator Wavelength: 940 nm (default) and 850 nm (replaceable)
Viewing Range At Night: 400 m
Replaceable IR Illuminator: Yes

Image Display

Display: 0.49 inch, OLED, 1920 × 1080
Palettes: Thermal: Black Hot, White Hot, Red Hot, Fusion; Optical: Day, Night, Auto
FFC (Flat Field Correction) Mode: Auto, Manual, External Correction
Exit Pupil: 8 mm
Eye Relief: 15 mm
Diopter (Range): -5 D to +3 D
Brightness Adjustment: Yes
Tone Adjustment: Cold, Warm
Contrast Adjustment: Yes
Zoom Pro: Yes

System

Record Video: Yes
Capture Snapshot: Yes
Audio Recording: Yes
Standby Mode: Yes
Storage: Built-in EMMC (64 GB)
PIP: Yes
Hotspot: Yes
Hot Track: Yes
Digital Magnetic Compass: Yes
GPS: Yes
Local Album: Yes

Power Supply

Battery Type: Replaceable and Rechargeable Li-ion 18650 Battery
Battery Operating Time: ≥8 h (25°C, with hotspot off)
Type-C

Power Supply: 5 V DC, 2 A

Support External

Power Supply

Supports Direct Charging

General

Protection Level: IP67
Dimension: 138.1 mm × 68.5 mm × 222.4 mm (5.44" × 2.7" × 8.75")
Working Temperature: -30°C ~ +55°C
Weight: 798 g without battery
Interpupillary Adjustment Range: 60 mm to 74 mm
Mounting Adapter: 1/4“-20-UNC

Product Code:HQ35L4K

Barcode:6974004640477

Brand:Huntsman Optics

Type:Bino/Monocular

Availability:In Stock
